Product Description:
Our steel structure warehouse is a perfect solution for various industries - commercial, industrial, and agricultural.
We offer both light and heavy-duty steel structures that are easy to assemble and prefabricated in our factory. With our team of designers and customer service, you will have all the support needed for your project.
Our warehouses have two types of surface treatments – painted and galvanized. The choice is yours, and we can help advise on the best option for your project.
Technical Parameters:
| Item |
Material |
Description and surface process |
| Main steel frame |
Column and Beam |
Q235 or Q355 |
H section steel with two coats of mid-gray paint |
| Purlin |
Q235 or Q355 |
Galvanized C or Z type steel |
| Connecting Pieces |
Tie tube |
Q235 |
Circular Tube with two coats of mid-gray paint |
| Knee-Bracing |
Q235 |
L50*4 Galvanized angle steel |
| Strutting piece |
Q235 |
φ12*2.5 Galvanized Circular Tube |
| Column Bracing |
Q235 |
Circular Tube with two coats of mid-gray paint |
| Horizontal Bracing |
Q235 |
Circular Tube with two coats of mid-gray paint |
| Casing |
Q235 |
φ30*2.5 Galvanized Circular Tube |
| Door and Window |
Item |
Description |
| Door |
Roller shutter door or Sliding door |
| Window |
PVC Window or aluminum alloy window |
| Other parts |
Ventilating device |
Fan,Ventilation window |
| Bolt |
Foundation bolt,High strengthen bolt, Normal bolts |
| Skylight |
Yx-840 Glass Fiber Reinforced Plastics |
| Out/Inner ridge tile |
0.50mm Color sheet |
| Crane beam |
Q235 or Q345 H section steel with two coats of mid-gray paint |
| Panel Material parts |
(1). External Wall panel: (below is selectable) |
| 1) 50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 4) 50- 250mm thickness PU sandwich panel |
| 3) 900# Corrugated Galvanized Steel sheet with different Color |
| 4) Kinds of PVC wall panel. |
| (2). Internal Wall panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| (3). Roofing panel: (below is selectable) |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel |
| 2) 50mm, 75mm or 100mm thickness glass wool sandwich panel |
| 3) 50mm, 75mm or 100mm thickness Rockwool sandwich panel |
| 3)Corrugated Steel Sheet, an insulating layer if need. |
| 4)Corrugated PVC roof panel. |
| (4). Skylight: 820# Glass Fiber Reinforced Plastics (FRP) |
This Steel Structure Warehouse product is designed for Custom Steel Fabrication . It can be equipped with an Intelligent Warehouse Management System to optimize operations. Additionally, it can be used as a Cold Room Warehouse with suitable insulation materials.
Applications:
The steel structure warehouse is suitable for various industries, including manufacturing, logistics, and retail. It can be used to store raw materials, finished products, machinery, and equipment. The warehouse can also be used as a distribution center, where products can be stored, sorted, and shipped to various locations.
The WH2766 model features a connect bolt/weld system, which ensures the strength and stability of the warehouse. The skylight is made of glass fiber reinforced plastics, which allows natural light to enter the warehouse. The raw steel material used for the warehouse is Q235B and Q355B, which are known for their durability and strength. The door type can either be a roller shutter door or sliding door, depending on the customer's preference. The purlin is made of galvanized C or Z type steel, which provides additional support to the structure.
Customization:
| Drawings & Quotation Information: |
| 1) Customized design is welcomed. |
| 2) Could you tell me your steel structure project? |
| Basic design requirements and design Load |
| 1. Project site location: |
| 2.Overall dimension(length*width*eave height in meters): |
| 3. Mezzanine or not?How many kgs of load per square meter on mezzanine? |
| 4. Single-layer steel sheet wall or sandwich panel wall: |
| 5. Snow load if applicable: |
| 6. Wind speed/load: |
| 7. Interior column allowed or not: |
| 8. Overhead crane needed or not, capacity?: |
| 9. Any other particular requirements?: |
| Building Purpose: we will recommend the best design for the purpose of the building |
| A.Warehouse/Storage |
| B.Factory |
| C.Agriculture Barn |
| E.Repair/Mechanic Shop |
| F.Office Space |
| G.Medical Warehouse |
| H.Animal Farm (please confirm what kind of animal) |
Support and Services:
Our Steel Structure Warehouse product comes with comprehensive technical support and services to ensure that your building is constructed safely and efficiently. Our team of experts can provide assistance with:
- Design consultation to ensure that your building meets your specific needs and requirements
- Engineering services to ensure that your building meets all relevant safety and building codes
- Installation support to assist with the proper assembly of your building
Our goal is to provide our customers with the best possible experience when purchasing and using our Steel Structure Warehouse product. If you have any questions or concerns, our technical support team is always available to assist you.
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to Qingdao port. And we have total 3 workshops from steel structure to wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity, partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution according to your requirements before placing order. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.
