Qingdao KXD Steel Structure Co., Ltd kxdandy@chinasteelstructure.cn 86--13853233236
Product Details
Place of Origin: QINGDAO, CHINA
Brand Name: KXD
Certification: ISO, CE
Model Number: KXD-S0001
Payment & Shipping Terms
Minimum Order Quantity: 500 square meter
Price: USD 50-70 per square meter
Packaging Details: steel pallet
Delivery Time: 30-40 working days
Payment Terms: T/T,L/C
Supply Ability: 15000 tons per month
Insulation Material: |
EPS , Glasswool, Rockwool, PIR |
Metal Sheet: |
High Corrosion Resist |
Workshop Visit: |
Acceptable |
Pitch Degree: |
10~30 Degree |
Material: |
Steel |
Standards: |
AISI, ASTM, BS, DIN, GB, JIS |
Foundation Type: |
Concrete Slab/Foundation Bolts |
Using Life: |
Over 50 Years |
Aesthetics: |
Modern/Contemporary |
Insulation Material: |
EPS , Glasswool, Rockwool, PIR |
Metal Sheet: |
High Corrosion Resist |
Workshop Visit: |
Acceptable |
Pitch Degree: |
10~30 Degree |
Material: |
Steel |
Standards: |
AISI, ASTM, BS, DIN, GB, JIS |
Foundation Type: |
Concrete Slab/Foundation Bolts |
Using Life: |
Over 50 Years |
Aesthetics: |
Modern/Contemporary |
|
There are two main types of construction steel materials : Q355 and Q235. |
|||
|
Q means “bend”, it is for the yield strength. Q235 is the minimum yield strength 235 Mpa. Q355 is the minimum yield strength 355 Mpa. |
|||
|
They are divided into 4 gardes, ABCD, such as Q235A , Q235B, Q235C, Q235D. ABCD refers to the impact test grade. Q355B and Q235B are the most popular. |
|||
|
Q355 is mainly used for main steel frame. Like column, beam, wind speed resistant column, crane girder... |
|||
|
Q235 is mainly used for secondary steel frame. Like tie bar, brace, vertical/horizontal support... |
|
Buildings’ structure Type |
Building service lifetime (years) |
||
|
Non-production processing building |
Production processing building |
Corrosive Production processing building |
|
|
Steel structure |
80 | 70 | 50 |
|
Reinforced Concrete structure |
60 | 50 | 35 |
|
Brick Concrete structure |
50 | 40 | 30 |
|
Wood and Brick structure |
40 | 30 |
20 |
Our Production Process after Drawing confirmed and detailed:
Raw Materials Preparation
various steel plates preparation, different profiles, like H sectional steel, angle steel, round tube, round steel and square tube etc., all accessories
Cutting, Drilling holes and Bending
By production drawings, right size, holes and shape are processing.
Assembly and Welding
Our welders will follow the drawings to assemble all steel members by welding them together as a entire beam/column/brace and so on;
Our quality inspector will check the steel pieces after finish welding. This process will go through the 1st quality check.
Sand blasting
After welding and polishing process finishing, rust remove by sand blasting will start. Our sand blasting effect can reach Sa2.5 Grade. This process will go through 2nd quality check.
Paint
Within 2 hours after sand blasting, all the steel members should be painted. Labors will paint as required color and thickness. This process will go through 3rd quality check.
Inspecting by clients
After we finish a part of fabrication work, we will invite clients to inspect the goods before we pack the steel components. If not available to inspect, we could send video for reference.
Steel pallet for shipping loading
Steel pallet will process for shipping loading process. Steel pallet will protect steel components surface coating and save loading space. Even unloading process cost will be also save by the best.
