Highlight:
famous prefab steel structure warehouse
, galvanized prefab warehouse building
, GB prefab metal warehouse
Standard: |
GB,ASTM,AISI,DIN,BS |
Purlin: |
C.Z Shape Steel Channel,C/Z Galvanized Steel(Q235) |
Surface Treatment: |
Hot Dip Galvanised,Blast Cleaning,Ball Blasting Or Painting,Galvanized |
Window: |
Aluminum Alloy,PVC Window,Plastic Steel Or Aluminum Alloy |
Roofing: |
Sandwich Panel. Single Steel Sheet,EPS Sandwich Panel, PU ,Rockwool |
Main Frame: |
H Beam And Comlumns,solid H-shape Steel Beam |
Beam: |
H Steel Available,Steel Pipes,Angle Steel,Welded/ Hot Rolled H Beam |
Door: |
Sliding Doors, Rolling Shutter Doors |
| Prefabricated Steel Structure Building Description: QINGDAO KXD STEEL STRUCTURE CO.,LTD |
KXD steel Buildings are used for workshops, Warehouses, Sheds, Hangars, Retail shops, Riding Arenas, Administrative offices, Homes, Garages, and even personal storage facilities. Whatever the application, we have a building for you.
Our Steel Structures are custom-designed to your needs. Our Metal buildings can be customized to incorporate Cranes, Mezzanines, Partitions, and Canopies, or they can be added to an existing Structure if you need that extra storage space. Accessories such as Windows, Man Doors, Louvres, Light-Transmitting Wall Panels, Liner Panels, and Insulation are available.
Product Description
Main steel structure
(columns and beams) |
1.Steel Q345(S355JR) or Q235(S235JR)H shape
2. Straight cross-section or Variable cross-section |
| Sub steel structure |
1.Material Q235(S235JR) steel
2. Bolt connections. Anti-rust painted or galvanized
3. Bracing: X-type or V-type or other type bracing made from angle, round pipe, etc
4. Purlin: C or Z type: Size from C80~C320, Z120~Z300 |
| Roof |
Sandwich panel(PU/EPS/fiberglass/rook wool) or Colorful steel tile |
| Wall |
Sandwich panel(PU/EPS/fiberglass/rook wool) or Colorful steel tile |
| Doors |
Steel rolling shutter or others |
| Windows |
Alu. Alloy windows, or others |
| Edge Cover |
Steel sheet 0.5mm thickness |
| Bolts |
M24, M22, M16 embedded bolts, intensive bolts, galvanized ordinary bolts,high-strength bolts, etc |
| Others options |
Skylight panel, Roof ventilator, Downpipe, Galvanized, Crane, sanitary Products |
| Foundation |
Cement and steel foundation bolts |
These Prefabricated Steel buildings are easy to assemble, energy efficient, attractive, economical over time, and can be shipped in as little as 5 weeks. Our Engineers and staff are always on standby to assist with complex projects.
Our steel structure building has a flexible layout, has low foundation cost, and can designed as per the buyer's requirement
1. Location (where will be built?) Which country? which city?
2. Size: Length * width * Eve height _______ mm * _______ mm * _______ mm
3. wind load (maximum. Wind speed) _____ kn/m2, _____ km/h, _____ m/s
4. snow load (maximum Snow height) _____ kn/m2, _____ mm, temperature range?
5. Anti-earthquake _____ level
6. brick wall needed or not If yes, is 1.2m high or 1.5m high? or other?
7. thermal insulation If yes, EPS, fiberglass wool, rock wool, and PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.
8. Door quantity&size _____ units, _____ (width) mm * _____ (height) mm
9. window quantity&size _____ units, _____ (width) mm * _____ (height) mm
10. crane needed or not If yes, _____ units, max. Lifting weight____tons; Max. Lifting height _____m
Product Parameters
Main steel structure frame :
Material: Weld H beam or hot rolled H beam etc
Grade:Q355 (S355JR)
Surface: Hot dip Galvanized zinc coated or Anti-rust paint rich-zinc epoxy paint etc
Usage: Make up the main steel structure frame
|
Strut (Tie beam) on eave and ridge:
Material: Round pipe or square tube etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint rich-zinc epoxy paint etc
Usage: Avoid the main steel structure frame shake in the length direction
X brace for roof and wall:
Material: Steel Round bar or angle steel etc
Grade:Q235 (S235JR)
Surface: Hot dip Galvanized zinc coat or Anti-rust paint rich-zinc epoxy paint etc
Usage: Make the whole structure stable,tie the whole building into one
● Windows and Doors
Plastic Steel Window/Aluminum-alloy Window; Sliding Door/Folding Door.
● Other Options:
The gutter, Downpipe, Transparent sheet, Ventilator, and Bridge Crane will be fitted according to the client’s requirements.
Our company can design, fabricate, load, and erect steel structure buildings according to clients’ needs.
1. Make suitable design plans and detailed construction drawings of steel structure buildings according to the land layout area and usage of buildings by Tekla, PKPM, and 3D3S.
2. Steel structure buildings consultation service.
3. Budget offers of building for contractors.
4. Transportation & delivery as your need.
5. Fabrication, shot blasting & painting as different requests.
6. Erection & installation of steel structure building. Our technicians and skilled workers can be on-site to guide or install the building as needed
Why Choose KXD Steel Structure Building?
1. One-stop service:
Total solution for projects; 3D model design; design drawing and construction drawing; online technical support; after service: return and replacement.
2. Well-equipped factory:
Our own factory-patented packaging and convenient transportation save you from worries.
3. High-quality products:
Our own professional research & development team and the QC team guarantee that our customers will receive products with perfect welding and accurate dimensions.
4. Rich experience:
Our products have been exported to America, Russia, Saudi Arabia, Canada, Romania, Sri Lanka, Malawi, British, the Philippines, Greece, South Africa, and so on.
5. Constantly develop:
We have been devoted to the research & development of steel structure buildings. And we constantly renovate technology to improve the wind- and rain-resistance performance of the products. So their lifespan can be enlarged and it helps accomplish the most cost-effective effect for our customers.
FAQ
Q: Are you a manufacturer or trading company?
A: We are a manufacturing factory, located in Qingdao City, near Qingdao Port. We have a total of 3 workshops from steel structures to wall and roof sheets.
Q: How about your quality control?
A: We have got certificates ISO & CE. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, and loading to ensure no quality defects.
Q: Is third-party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client requirements.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity, partial shipment is allowed for big orders.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey jobs for some kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: The sales and engineering team will provide you a suitable solution according to your requirements before placing an order. Proposal drawings, Shop drawings, 3D drawings, Materials photos, and Finished projects photos are available, which will help you understand the solution we provided deeply.
