40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar

Product Details

Place of Origin: China Qingdao

Brand Name: KXD

Certification: ISO9001:2008

Model Number: KXD-SW22

Payment & Shipping Terms

Minimum Order Quantity: 200 square meters

Price: USD 40-85 Per Square meter

Packaging Details: steel pallet & wooden box or in bulk

Delivery Time: 35-55 days

Payment Terms: T/T, L/C

Supply Ability: 5000-9000 tons Per Month

Get Best Price
Product Details
Highlight:

Warehouse Steel Frame Buildings

,

Hangar Steel Frame Buildings

,

Workshop Steel Frame Buildings

Profile:
Hot Rolled H Steel / Weld H Steel
Material:
Q355b, Q235b
Technician:
Free Technical Support
Design:
Custom Exactly As The Demands
Drawing:
3D Model And Installing Drawing Available
Production:
Finished For Direct Install Support
Coating:
Alkyd Painting, Epoxy Painting, Hot Dip Galvanized
Insulation:
EPS, Glasswool, Rockwool, PU On Option
Standard:
Different Standards On Option As Demands
Install:
Online Guide Support & On-site Install
Service Life:
30-50 Years
Visit:
Workshop Visit And Check Available
Profile:
Hot Rolled H Steel / Weld H Steel
Material:
Q355b, Q235b
Technician:
Free Technical Support
Design:
Custom Exactly As The Demands
Drawing:
3D Model And Installing Drawing Available
Production:
Finished For Direct Install Support
Coating:
Alkyd Painting, Epoxy Painting, Hot Dip Galvanized
Insulation:
EPS, Glasswool, Rockwool, PU On Option
Standard:
Different Standards On Option As Demands
Install:
Online Guide Support & On-site Install
Service Life:
30-50 Years
Visit:
Workshop Visit And Check Available
Product Description

40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 0

40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 1

40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 2



General class configuration.
① Building type:
Portal frame construction.
② Type of main steel structure:
The main steel structure of this kind of building uses welding H type members more, but also box type members, cross type members, T type members and other component types.
③ Secondary steel structure:
Column support, horizontal support, tie bar, stairs, guardrail, etc.
④ Cladding system:
Type C /Z purlin, round steel, bracket, casing.
The roof and wall are often made of pressed color steel plate, ACC prefabricated wall panel, sandwich board.
⑤ Galvanized standard, paint type and color:
Customize according to actual architectural application requirements and your specific requirements.
40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 3
Services offered by KXD STEEL STRUCURE:

Always online consulting service:

-Professional, Fast, Free support



Design and Quotation

-For free, Meticulous Plan, Detailed materials list



Whole Project Solution

-Comprehensive design and solution for several terms of your project



High Quality Materials

-Use high quality materials of every components to guarantee details

40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 4

Welding Robot.

Improve welding accuracy, Improve work efficiency and reduce labor intensity.

CNC Intersecting Wire Cutting Machine.

It can cut large-diameter round pipes with high precision and improve work efficiency.

CNC Plasma Flame Cutting Machine.

High-precision transmission cutting, stable operation and stable quality.

CNC Section Steel Automatic Cutting Machine.

It can perform 3D modeling data file cutting of TEKLA steel structure deepening software, fine hole cutting, intelligent planning line marking.

Automatic Assembly Machine.

Automatic control can be realized, the production efficiency is more than doubled, and the quality is stable and reliable.

High Speed ​​3D CNC Drilling Machine.

High-precision processing to meet the needs of various aperture applications.

40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 5



40' Container Loading Prefabricated Steel Frame Buildings For Warehouse Workshop Hangar 6

Steel Structure Fame Light weight steel structure
Roof & Wall Cladding system Steel sheet; Sandwich panel
Sandwich panel thickness 50-100mm
Door Material Sandwich panel door; Security door
Window Material Plastic steel window; Aluminum allow edge window

Description:

1, Prefabricated house is made of light steel as steel structure and steel plate/ sandwich panels/ALC Panel/Aluminium board/Concrete wall for wall and roof

2,The sandwich panels can be polystyrene, polyurethane, rock wool, and fiber glass sandwich panels for insulation, thickness could be 50,75,100,150,200mm

3,The steel structure main beams and contents are prefabricated in our workshop and connected by high-strength bolts, no need too much welding at site.

4,The steel structure building is a permanent building with the service life of over 70 years

Characteristics:

1,Environment protective, no garbage caused

2,Doors, windows, and interior partitions can be flexibly fixed

3,Beautiful appearance, different colors for the wall and roof

4,Cost saving and transportation convenient

5,Anti-rust and normally more than 70years using lifespan

6,Safe and stable, can stand 8 grade earthquake

Technical parameter of standard prefabricated house:

1,Wind resistance:Customized, could resistant typhoon/hurricane

2,Earthquake resistance: grade 8

3,Live load capacity of roofing: normally 0.5kN/m², could be customized

4,External and internal wall heat transmission coefficient: 0.35Kcal/m2hc

5,Second floor load capacity: normally 150kg/m², could be customized

6,Live load of corridor: 2.0kN/m²

7,We can design and produce the house according to customer’s request
