Customized High Strength Pig Feeding System For Livestock Piglet

Name: Customized High Strength Pig Feeding System For Livestock Piglet
Brand: Qingdao KXD Steel Structure Co., Ltd
SKU: KXD-PIGGERY EQUIPMENT
Price: 115.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: KXD

Certification: CE, ISO 9001, ISO140001, ISO45001

Model Number: KXD-PIGGERY EQUIPMENT

Payment & Shipping Terms

Minimum Order Quantity: 10 sets

Price: 30-200 USD per set

Packaging Details: Steel Pallet Or In Bulk

Delivery Time: 10-20 days

Payment Terms: L/C,T/T,Western Union,MoneyGram

Supply Ability: 10000 sets per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                High Strength Pig Feeding System, Customized Pig Feeding System


Name:	Pig Feeding System	Drinker Bowls:	Stainless Steel 304
Plastic Floor:	600x400mm, 600x500mm,600x600mm Or Customized	Cool Pad:	1800x600x150mm Or Customized
White Curtain:	PE, 330g/m2 (pre Made)	Saddle:	ABS Alloy Material
Dry/Wet Feeder:	Stainless Steel For Base Pan,PVC Barrel	Application:	For Mating Shed, Farrowing Shed, Weaner Shed, Grower Shed
Free Feeder:	5-level Adjustable	Heat System:	Includes Heat Lamp, Insulation Cover, Heat Pad Etc.
Other Accessories:	Medium Board, Paddles, Stainless Steel Clamp, Laneway Pens Etc. Bracket,	Feeder Size:	900550470 Mm/Customizable

Name:	Pig Feeding System
Drinker Bowls:	Stainless Steel 304
Plastic Floor:	600x400mm, 600x500mm,600x600mm Or Customized
Cool Pad:	1800x600x150mm Or Customized
White Curtain:	PE, 330g/m2 (pre Made)
Saddle:	ABS Alloy Material
Dry/Wet Feeder:	Stainless Steel For Base Pan,PVC Barrel
Application:	For Mating Shed, Farrowing Shed, Weaner Shed, Grower Shed
Free Feeder:	5-level Adjustable
Heat System:	Includes Heat Lamp, Insulation Cover, Heat Pad Etc.
Other Accessories:	Medium Board, Paddles, Stainless Steel Clamp, Laneway Pens Etc. Bracket,
Feeder Size:	900550470 Mm/Customizable

Product Description

Feeding System For Farm Customized Feeder For Livestock Piglet

Steel Structure Piggery Shed

Steel structure Piggery House is a structure composed of steel materials and is one of the main types of building structures. The structure is mainly composed of steel beams, steel columns, steel trusses and other components made of section steel and steel plates. The characteristics of steel are high strength, light weight, good overall rigidity, and strong resistance to deform.

Customized High Strength Pig Feeding System For Livestock Piglet 0

Chain-disc Feeding System

Customized High Strength Pig Feeding System For Livestock Piglet 1

Piglet Feeding Trough

Auger Feeding System

Customized High Strength Pig Feeding System For Livestock Piglet 3

60 Feeding Corner

275g hot galvanized or 304 stainless steel housing, thanks to the groove design to have better airtightness, with thickness 1.5mm/2.0mm.

With silicon sealer, moisture proof and waterproof,no fed accumulation, feed not easy to be dry and hard and mildew; Robust and durable casting steel runner with ball bearing to reduce chain wear.

Customized High Strength Pig Feeding System For Livestock Piglet 4

60 Feeding Chain

Thanks to the speialalloy material,the chain has advantages of light weight, but high strength, breaking load over1.8KN.

Material of Chain-disc is high strength nylon 66 material, it's strong and light, space between each disc is92mm.

With special driving system, force impose on chain-disc, which has long transfer distance and service life.

Customized High Strength Pig Feeding System For Livestock Piglet 5

Other Accessories

KXD knows that it takes a lot to feed your pigs. That’s why we offer top of the line products to help you store your feed and easily transport it into your barns.

Customized High Strength Pig Feeding System For Livestock Piglet 6

Customized High Strength Pig Feeding System For Livestock Piglet 8

On-site Installation

Customized High Strength Pig Feeding System For Livestock Piglet 9

Package & Unloading Containers

Customized High Strength Pig Feeding System For Livestock Piglet 12

Customized High Strength Pig Feeding System For Livestock Piglet 13
