Modular Warehouse Custom Prefab Building Industrial Prefabricated Steel Structure Workshop
Product Description:
|
Specifications:
|
|
Main Steel Frame
|
H section steel beam and columns, painted or hot dip galvanizing, galvanized C section or steel pipe
|
|
Secondary Frame
|
Hot dip galvanized C purlin, steel bracing , tie bar , knee brace , edge cover etc.
|
|
Roof Panel
|
Steel sheet, Alum-Zinc sheet , Alumnium sheet, EPS sandwich panel,glass fiber sandwich panel,rock wool sandwich panel,and PU sandwich panel etc.
|
|
Wall Panel
|
Sandwich Panel or Corrugated Steel Sheet etc.
|
|
Tie Rod
|
Circular Steel Tube
|
|
Brace
|
Round Bar
|
|
Knee Brace
|
Angle Steel
|
|
Roof Gutter
|
Color Steel Sheet, Alum-zinc sheet, Gal. sheet, Stainless steel
|
|
|
(1) Customized design is welcomed. We will quote for you promptly.
|
|
(2) In order to give you an exactly quotation and drawings, please let us know the length, width, eave height and local weather.
|
Features:
- Product Name: Steel Structure Workshop
- Features: Commercial Steel Frame Building for Auto Service Shop
- Warranty Period: 50 Years
- Door Type: Sliding/Rolling/Sectional
- Color: Customer's Requirement
- Main Material: Steel Structure Frames
- Suitable for: Building Facilities And Construction Materials
- Perfect for: Construction Project
| Specifications |
| 1)Size(m): |
Width * Length * Height; |
| 2)Type: |
Single slope, double slope, Multi-slope; |
| Single span, double-span, Multi-span; |
| Single floor, double-floor, Multi-floor; |
| 3) Base: |
steel foundation bolts |
| 4) Steel frame: |
Material Q345(S355JR)(Gr50)or Q235(S235JR) steel; |
| Straight cross-section or Variable cross-section; |
| steel welded H section painted or galvanized. |
| 5) Bracing: |
X-type or V-type or other type bracing made from angle, round bar, etc ; |
| 6) Wall & Roof Purlin: |
C section channel or Z section channel ,Size from C80~C300; Z100~Z300; |
| 7) Roof & wall cladding |
Single color corrugated steel sheet 0.326~0.7mm thickness; |
| Sandwich panel with EPS, ROCK WOOL,GLASS WOOL, PU etc insulation, thickness around 50mm 75mm 100mm 120mm 150mm 200mm; |
| recommend coating PVDF SMP HDP PE |
| 8)Window: |
UPVC/PVC or Aluminum Alloy window frame with glass. |
| 9)Door: |
Exterior door:Sliding or Roller shutter door. |
| Internal door:50mm thickness EPS sandwich panel with an aluminum alloy door frame |
| 10) Gutter material: |
Color steel sheet or galvanized steel or stainless steel; |
| 11)Rainspout: |
PVC pipe |
| 12)Connection |
high strength bolts ,intensive bolt,self-drilling screws. |
| 13)Accessories: |
Skylight panel, Ventilation, Fasteners etc |
| 14)Surface process: |
Shot blasting Sa2.5;Two layers of Anti-rust Painting or galvanized |
| 15) Packing: |
Main steel frame without packing load in 40' GP, roof and wall panel load in 40' HQ |
Applications:
Our steel structure workshop is suitable for a variety of building facilities and construction materials. It is a versatile building that can be used for a wide range of applications, including:
- Commercial steel frame building
- Industrial manufacturing
- Agriculture
- Warehouse storage
- Garage or carport
Support and Services:
FAQ:
Q:Are you manufacturer or trading company?
A:We are manufacture factory, located in Qingdao city, near to Qingdao port. And we have total 3 workshops from steel structure to wall and roof sheet.
Q: How about your quality control?
A: We have got certificate ISO & CE. Products processing through cutting, bending, welding, shot blasting, ultrasonic testing, packing, storing, loading to ensure no quality defects.
Q: Is third party inspection available?
A: SGS, BV, TUV, etc. are available, it is according to client requirement.
Q: How about your delivery time?
A: Generally within 30-45 days, it is according to order quantity, partial shipment is allowed for big order.
Q: What about the installation?
A: We'll provide the detailed installation drawing, supervisors guiding installation is available. We can do turnkey job for some kind of projects.
Q: How to ensure the product you supply is what we want exactly?
A: Sales and engineer team will provide you the suitable solution according to your requirements before placing order. Proposal drawing, Shop drawing, 3D drawing, Materials photos, Finished projects photos are available, which will help you understand the solution we provided deeply.
