HDG Metal Construction Building Prefabricated Warehouse Steel Frame Office Building

Product Details

Place of Origin: China Qingdao

Brand Name: KXD

Certification: ISO9001:2008

Model Number: KXD-SW18

Payment & Shipping Terms

Minimum Order Quantity: 200 square meters

Price: USD 40-85 Per Square meter

Packaging Details: steel pallet & wooden box or in bulk

Delivery Time: 35-55 days

Payment Terms: T/T, L/C

Supply Ability: 5000-9000 tons Per Month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                HDG Metal Construction Building, Office Metal Construction Building, Prefabricated Steel Frame Office Building


Profile:	Hot Rolled H Steel / Weld H Steel	Material:	Q355b, Q235b
Technician:	Free Technical Support	Design:	Custom Exactly As The Demands
Drawing:	3D Model And Installing Drawing Available	Production:	Finished For Direct Install Support
Coating:	Alkyd Painting, Epoxy Painting, Hot Dip Galvanized	Insulation:	EPS, Glasswool, Rockwool, PU On Option
Standard:	Different Standards On Option As Demands	Install:	Online Guide Support & On-site Install
Service Life:	30-50 Years	Visit:	Workshop Visit And Check Available

Profile:	Hot Rolled H Steel / Weld H Steel
Material:	Q355b, Q235b
Technician:	Free Technical Support
Design:	Custom Exactly As The Demands
Drawing:	3D Model And Installing Drawing Available
Production:	Finished For Direct Install Support
Coating:	Alkyd Painting, Epoxy Painting, Hot Dip Galvanized
Insulation:	EPS, Glasswool, Rockwool, PU On Option
Standard:	Different Standards On Option As Demands
Install:	Online Guide Support & On-site Install
Service Life:	30-50 Years
Visit:	Workshop Visit And Check Available

Product Description

Rockwool Insulated Steel Roof Wall Prefabricated Steel Frame Warehouse Office Building HDG Metal Construction Building Prefabricated Warehouse Steel Frame Office Building 0

Your prefabricated steel structure building will be supplied as following:

1)All Steel structure Frame parts with prefabricated. (hole,weld,surface treatment etc)

2)All the Roof and Wall Panels already cut to size for your size structure.

3)Completely window and door with hinge,handle etc hardware

4)Bolts, Screws and pop-rivets needed to secure your structure.

5)flashing and Silicone to further help insulate your structure.

6)Other Accessories you have choose: gutter,water spout,ventilation fitting,stairs etc

7)Other internal simple equipment:LED light,shelf racks etc

Main steel structure frame	Tie beam on eave and ridge	X brace for roof and wall	Purlin
Material: Weld H beam or hot rolled H beam etc	Material: Round pipe or square tube etc	Material: Steel Round bar or angle steel etc	Material: C/Z purlin etc Size:80~300mm,thickness1.8~3.0mm
Grade:Q355 (S355JR)	Grade:Q235 (S235JR)	Grade:Q235 (S235JR)	Grade:Q355 (S355JR)
Surface: Hot dip Galvanized coat	Surface: Hot dip Galvanized coat	Surface: Hot dip Galvanized coat	Surface: 100-275g Galvanized zinc coating
Usage: Make up the main steel structure frame	Usage: Avoid the main steel structure frame shake in length direction	Usage: Make the whole structure stable,tie the whole building into one	Usage: For supporting protection structure and install cladding panels

Prefabricated Steel Structure Building
ITEMS	SPECIFICATION
Main Steel:	Q355B, Q235B, etc.
Anti-rust protection	Hot-dip galvanized or anti-rust painting
Purlin and girts	Cold-rolled C or Z steel, Q355 or Q235
Column & Beam:	Welded or Hot rolled H-section
Connection method of steel structure:	Welding connection or bolt connection
Wall & Roof:	Sandwich panel or steel sheet.
Door:	Rolled up door or Sliding door
Window:	Plastic steel or Aluminum alloy window
Surface:	Hot-dip galvanized or painted
Crane:	5MT, 10MT, 15MT, and more
Drawings & Quotation Information:
1) Customized design is welcomed.
2) Could you tell me your steel structure project?
Basic design requirements and design Load
1. Project site location:
2.Overall dimension(lengthwidtheave height in meters):
3. Mezzanine or not?How many kgs of load per square meter on mezzanine?
4. Single-layer steel sheet wall or sandwich panel wall:
5. Snow load if applicable:
6. Wind speed/load:
7. Interior column allowed or not:
8. Overhead crane needed or not, capacity?:
9. Any other particular requirements?:
Building Purpose: we will recommend the best design for the purpose of the building
A.Warehouse/Storage
B.Factory / workshop
C.Agriculture Barn
E.Repair/Mechanic Shop
F.Office Space / Mall / Gym
G.Medical Warehouse
H.Animal Farm (please confirm what kind of animal)

We really boast of suitable designs and high-quality products. You can find our own professional research & development team and the QC team guarantee that our customers will receive products with perfect welding and accurate dimensions. In addition, well-equipped factory, patented packaging and convenient transportation save you from worries.

Installation: Upon customer request, we could send our engineer to guide the installation, or a small team to install at the same time, teaching local workers to install, or enough workers to install all the goods by ourselves. It depends on whether the cost is economic.
